Working voltage:
|
AC100-277V, 50/60Hz
|
|||
|
PF:
|
> 0.97
|
|||
|
TECHNICAL CHARACTERISTICS
|
||||
|
Color:
|
Warm White
|
Natural White
|
Cool White
|
|
|
Color Temperature:
|
2700-3200K
|
4000-5500K
|
6000-6500K
|
|
|
CRI:
|
>70Ra, can be over 80Ra
|
>70Ra, can be over 80Ra
|
>70Ra, can be over 80Ra
|
|
|
Lumens:
|
140LM/W
|
|||
|
IP Rating: IP20
|
||||
|
CONFIGURATIONS
|
||||
|
LED chip:
|
Well-known Brand 3030 SMD, 5050 SMD
|
|||
|
LED driver:
|
Mean Well, SOSEN
|
|||
|
Heat sinks:
|
Aluminum
|
|||
|
Body color:
|
White
|
|||
|
OTHERS
|
||||
|
Operating Temperature:
|
-35℃ to 50℃
|
|||
|
Operating Humidity:
|
10%-90% RH
|
|||
|
Storage Temperature:
|
-35℃ to 60℃
|
|||
|
Warranty:
|
7 Years
|
|||
|
Certificates:
|
TUV, SAA, RCM, CE, RoHS, ETL
|
|||
| Model | LED (Pcs) | Wattage (W) | Colour | Lumens (Lm) | Size (mm) |
Beam Angle(°) |
Input Voltage(V) |
Waterproof (IP) | Download |
| OB-LHBL-2FT-100W | 100W | WW,NW,CW | 14,000Lm |  |
|||||
| OB-LHBL-2FT-150W | 150W | WW,NW,CW | 19500Lm | |
|||||
| OB-LHBL-3FT-200W | 200W | WW,NW,CW | 28,000Lm | |
|||||
| OB-LHBL-4FT-240W | 240W | WW,NW,CW | 33,600Lm | |
|||||
| OB-LHBL-4FT-300W | 300W | WW,NW,CW | 42,000Lm | |
